The NSR 4824 Extra-Flexible Silicone Motor Wire is designed for slot car electrical installations, providing a flexible connection between the motor and pickup guide. Its silicone insulation allows the wire to bend easily as the guide moves, helping maintain reliable electrical contact without restricting steering movement.
Supplied in a convenient 1-metre length with 10 brass motor-wire cups, this wire can be cut to the required length for individual installations and replacement wiring.
Technical Specifications
Manufacturer
NSR
Part Number
4824
Product
Extra-flexible silicone motor wire
Conductor Cross-Section
0.25 mm²
Insulation
Silicone
Wire Length
1 metre
Brass Motor-Wire Cups
10 included
Application
Slot car motor and pickup-guide wiring
Installation
Cut the wire to the required length for your installation.
Use the supplied brass cups to connect the wire to compatible motor terminals.
Allow sufficient wire movement for the pickup guide to turn freely from side to side.
Route and secure the wire so it cannot interfere with the front axle or other moving components.
Pack contents: 1 × 1-metre length of NSR 0.25 mm² silicone motor wire and 10 × brass motor-wire cups.
