RevoSlot RS0320 Ford Mustang GTO Complete White Body & Chassis Kit
RevoSlot RS0320 Ford Mustang GTO Complete White Body & Chassis Kit
SKU:RS0320
Regular price
$110.00 AUD
Regular price
Sale price
$110.00 AUD
Shipping calculated at checkout.
Quantity
Out of stock
Couldn't load pickup availability
RevoSlot RS0320 Ford Mustang GTO Complete White Body & Chassis Kit 1:32 Slot Car
The RevoSlot RS0320 provides a complete, unpainted white body kit of the iconic Ford Mustang GTO paired with high-performance chassis mechanics. Designed for custom painters and club racers building a personalized livery, this 1:32 scale analog slot car kit includes all clear windows, light lenses, mirrors, wing components, and a pre-assembled metal chassis system co-developed with BRM Model Cars.
Kit Overview & Theme
- Model: Ford Mustang GTO
- Edition: Complete Unpainted White Kit (Assembly & Painting Required)
- Includes: Unpainted body shell, clear windows/lenses, detail parts, and complete metal chassis assembly
Complete Technical Specifications & Parts Catalog
| Model Item SKU | RS0320 |
| Barcode (EAN) | Not Listed by Manufacturer |
| Scale | 1:32 Scale |
| Chassis Base Plate | RS525 — Aluminum Anodized Chassis Plate |
| Body Plate | RS524 — Aluminum Anodized Body Plate |
| Motor | RS211-B — 21,000 RPM Motor + Wires for GR.2/IMSA Models |
| Motor Holders | RS223 — Aluminum Motor Holders + Screws + Photo-Etch |
| Pinion Gear | RS232 — 9T Brass Pinion Ø 5.5mm (x2) |
| Spur Gear | RS227 — Nylon with Aluminum Hub AW Spur Gear 24T - Ø 14mm + M3 Screw (x1) |
| Front & Rear Axles | RS209 — 3x50mm Steel Axles |
| Axle Bearings | S-410 — Ball Bearings 3x6mm Flanged (x2) |
| Front Axle Holders | RS255 — Front Axle Holders (x2) |
| Rear Axle Holders | RS256 — Rear Axle Holders + Screws (x2) |
| Front & Rear Aluminum Wheels | RS252 / RS253 — RS252 Front & RS253 Rear Aluminum Wheels + M3 Screws |
| Front Tires | RS250 — Hard Front Tires (x4) |
| Rear Tires | RS251M — Rear Tyres STANDARD 30 Shore (x4) 20.5x10mm |
| Guide Blade Assembly (7mm) | RS210 — Guide 7mm Depth (x2) |
| Wood Track Guide (9mm) | RS210W — Guide 9mm Depth Wooden Tracks (x2) |
| Guide Spring | RS210SP — Guide Spring (x2) |
| Guide Screws | RS210S — Guide Steel Screws (x2) |
| Chassis Floating Hardware | RS208 — Brass Nuts (x4) + Screws for Chassis Floating |
| Full Screw Set | RS213 — Full Set of Screws |
Key Design Features
- Metal Chassis Setup: Uses a floating anodized aluminum chassis system (RS525/RS524) co-developed with BRM to decouple motor vibration from the body.
- Full Ball Bearing Drivetrain: Features flanged 3x6mm ball bearings (S-410) supporting 3x50mm steel axles (RS209).
- Anglewinder Gear Setup: Factory fitted with a 9T brass pinion (RS232) and a 24T AW nylon spur gear with aluminum hub (RS227).
- Dual Guide Inclusion: Ships with both standard 7mm (RS210) and deep 9mm wooden track (RS210W) guide blades.
