Scaleauto SC-6353R Audi R8 LMS GT3 #75 Jamec Pem Racing Bathurst 12 Hour 2017 1/32 Slot Car
Scaleauto SC-6353R Audi R8 LMS GT3 #75 Jamec Pem Racing Bathurst 12 Hour 2017 1/32 Slot Car
SKU:SC-6353R
Low stock: 3 left
Couldn't load pickup availability
Scaleauto SC-6353R Audi R8 LMS GT3 #75 – Bathurst 12 Hour 2017
The Scaleauto SC-6353R is a 1/32 scale R-Series race-version replica of the Audi R8 LMS GT3 #75 entered by Jamec Pem Racing in the 2017 Liqui-Moly Bathurst 12 Hour at Mount Panorama.
Finished in the distinctive Valvoline/Jamec Pem Racing livery, this R-Series model is equipped with Scaleauto's performance-oriented R2.0 chassis, an anglewinder drivetrain, adjustable front axle height, aluminium rear wheels, bronze spherical bearings and a removable traction magnet.
The Real Car – Bathurst 12 Hour 2017
The full-size Audi R8 LMS #75 was driven by Garth Tander, Christopher Mies and Christopher Haase for Jamec Pem Racing at the 2017 Bathurst 12 Hour. The Audi qualified 14th and completed 282 laps to finish 13th overall.
The #75 entry is particularly relevant to Australian slot car collectors, representing one of the Audi R8 LMS GT3s entered by the Australian Jamec Pem Racing team at Mount Panorama in 2017.
Key Features
- Scaleauto SC-6353R R-Series race version
- 1/32 scale Audi R8 LMS GT3
- Jamec Pem Racing #75 – Bathurst 12 Hour 2017
- Analogue operation
- Anglewinder drivetrain
- Scaleauto SC-0011b Tech-1 long-can motor
- 20,000 rpm motor specification
- 11:27 gearing
- Scaleauto RT3 anglewinder motor mount with -1 mm offset
- Adjustable front axle ride height
- Plastic front wheels
- Aluminium rear wheels
- Bronze spherical axle bearings
- Scaleauto SC-1608 advanced screw guide
- Removable traction magnet
- Standard-compound front and rear tyres
- No factory lighting
Specifications & Fitted Components
| Component | Fitted specification | Manufacturer code |
|---|---|---|
| Body | Audi R8 LMS GT3, Jamec Pem Racing #75, Bathurst 12 Hour 2017; detailed plastic body | SC-6353R |
| Chassis | Scaleauto R-Series R2.0 chassis | Model-specific chassis reference not independently verified |
| Motor | Tech-1 long-can, 20,000 rpm specification | SC-0011b |
| Motor mount | RT3 anglewinder mount, -1 mm offset, red, race specification | SC-6528C |
| Pinion gear | 11-tooth nylon anglewinder pinion | Exact fitted Scaleauto spare-part reference not independently verified |
| Crown gear | 27-tooth nylon anglewinder crown with aluminium hub | Exact fitted Scaleauto spare-part reference not independently verified |
| Gear ratio | 11:27 | — |
| Front wheels | Plastic; approximately 18.3 / 15.5 mm × 8.5 mm | Exact fitted wheel reference not independently verified |
| Rear wheels | Aluminium; approximately 17.5 / 15.5 mm × 8.5 mm | Exact fitted wheel reference not independently verified |
| Front tyres | Standard compound; nominal 18 × 9 mm | Exact fitted tyre reference not independently verified |
| Rear tyres | Standard compound; nominal 19 × 10.5 mm | Exact fitted tyre reference not independently verified |
| Axles | Steel axles, approximately 2.38 mm diameter × 52 mm length | Exact fitted axle reference not independently verified |
| Axle bearings | 3/32-inch bronze spherical bearings | Exact fitted bearing reference not independently verified |
| Guide | Advanced screw-in guide with spring and large angular movement | SC-1608 |
| Guide screw | M3 guide fixing screw | Exact fitted screw reference not independently verified |
| Magnet | Removable traction magnet mounted beneath the rear axle | Exact fitted magnet reference not independently verified |
| Lighting | No factory lighting | — |
Technical Specifications
| Specification | Details |
|---|---|
| Manufacturer | Scaleauto |
| Product code | SC-6353R |
| Scale | 1:32 |
| System | Analogue |
| Motor configuration | Anglewinder |
| Drive | Rear-wheel drive |
| Motor | Scaleauto SC-0011b Tech-1 long-can, 20,000 rpm |
| Gearing | 11:27 |
| Front axle adjustment | Height adjustable |
| Suspension | No chassis suspension fitted |
| Magnet | Yes – removable |
| Lighting | No |
| Wheelbase | Approximately 95 mm |
| Rear track | Approximately 62 mm |
| Overall dimensions | Approximately 137 mm long × 62 mm wide |
| Weight | Approximately 92 g |
Why Choose the Scaleauto R-Series?
The R-Series versions of Scaleauto's 1/32 GT cars are designed around higher-performance running rather than simply reproducing the appearance of the standard models. The SC-6353R combines the Audi R8 LMS body with an R-Series chassis, separate anglewinder motor mount, adjustable front axle, spherical bearings, screw-in guide and aluminium rear wheels.
The result is a highly tunable 1/32 GT3 slot car that can be set up for serious club racing as well as collection and display.
